SYNT50L轴承

d_a - 50 mm

A - 70 mm

B - 65 mm

H - 131 mm

H₁ - 70 mm

H₂ - 28 mm

J - 210 mm

L - 255 mm

H - 24 mm

N₁ - 18 mm

S - 2.5 mm

J₆ - 234 mm

J₇ - 26 mm

N₄ - max. - 8 mm

A₃ - 62 mm

A₅ - 29.5 mm

b_a - min. - 34 mm

b_a - max. - 55 mm

Basic dynamic load rating - C - 104 kN

Basic static load rating - C₀ - 108 kN

Fatigue load limit - P_u - 11.8 kN

Limiting speed - 3300 r/min

Calculation factor - e - 0.24

Calculation factor - Y₁ - 2.8

Calculation factor - Y₂ - 4.2

Diameter - d_m - 70 mm

Basic Designation bearing - 22210 E

P_a - 15 kN

P_0° - 190 kN

P_55° - 330 kN

P_90° - 200 kN

P_120° - 130 kN

P_150° - 115 kN

P_180° - 140 kN

Mass bearing unit - 5.8 kg

Diameter - G - 16 mm
