SYFWR1.1/2YZTHR轴承

d - 38.1 mm

A - 41 mm

A₁ - 33 mm

A₅ - 32 mm

B - 49.2 mm

H - 100 mm

H₁ - 49.2 mm

J - 88.9 mm

L - 114.5 mm

s₁ - 30.2 mm

R_G - 1/4-28 UNF

R₁ - 3.5 mm

R_α - 45 °

Basic dynamic load rating - C - 26 kN

Basic static load rating - C₀ - 19 kN

Fatigue load limit - P_u - 0.8 kN

Limiting speed - 2800 r/min

Calculation factor - f₀ - 14

Weight - 1.9 kg

Thread - G - M12

Thread length - G₁ - 19 mm

Hexagonal key size for grub screw - H - 3.969 mm

Recommended tightening torque for grub screw - 6.5 N·m

Housing - SYFWR 508 Y

Bearing - YAR 208-108-2RFGR/HV

End cover -
