SY55LF轴承

d - 55 mm

d - 56.67 mm

A - 60 mm

A₁ - 40 mm

A₅ - 34 mm

B₁ - 49 mm

H - 126 mm

H₁ - 63.5 mm

H₂ - 24 mm

J - 171.5 mm

J - max. - 181 mm

J - min. - 162 mm

L - 219 mm

H - 27.5 mm

N₁ - 18 mm

s₁ - 29 mm

J₆ - 201 mm

J₇ - 21 mm

N₄ - 4 mm

D_N - 6.5 mm

SW_N - 7 mm

G_N - 1/4-28 SAE-LT

R_G - 1/4-28 UNF

R₁ - 4.5 mm

R_α - 45 °

Basic dynamic load rating - C - 43.6 kN

Basic static load rating - C₀ - 29 kN

Fatigue load limit - P_u - 1.2 kN

Limiting speed - 3600 r/min

Weight - 3.35 kg

Hexagonal key size for grub screw - H - 3 mm

Recommended tightening torque for grub screw - 7.4 N·m

SKF - 626830
