SY1.11/16LDW轴承

d - 42.862 mm

d - 44.53 mm

A - 48 mm

A₁ - 32 mm

A₅ - 23 mm

B₁ - 44 mm

H - 107 mm

H₁ - 54 mm

H₂ - 21 mm

J - 143.5 mm

J - max. - 152 mm

J - min. - 135 mm

L - 187 mm

H - 22.5 mm

N₁ - 14 mm

s₁ - 26.5 mm

J₆ - 173 mm

J₇ - 17 mm

N₄ - 4 mm

Basic dynamic load rating - C - 33.2 kN

Basic static load rating - C₀ - 21.6 kN

Fatigue load limit - P_u - 0.915 kN

Limiting speed - 850 r/min

Weight - 2.2 kg

Hexagonal key size for grub screw - H - 3 mm

Recommended tightening torque for grub screw - 7.4 N·m

SKF - 626830
