FYTWR1.1/4YTHR轴承

d - 31.75 mm

A - 35.7 mm

A₁ - 14.3 mm

A₅ - 30.5 mm

B - 42.9 mm

B₄ - 6 mm

D_b1 - 87 mm

D_b2 - 92.1 mm

J - 130.2 mm

H - 155.6 mm

L - 92.1 mm

H - 14.3 mm

s₁ - 25.4 mm

T - 46 mm

R_G - 1/4-28 UNF

R₁ - 24 mm

R_α - 45 °

Basic dynamic load rating - C - 21.6 kN

Basic static load rating - C₀ - 15.3 kN

Fatigue load limit - P_u - 0.655 kN

Limiting speed - 3200 r/min

Mass bearing unit - 1.4 kg

Thread - G₂ - 5/16-24 UNF

Hexagonal key size for grub screw - H - 3.969 mm

Recommended tightening torque for grub screw - 6.5 N·m
