FYT1.3/4RM轴承

d - 44.45 mm

A - 39 mm

A₁ - 14 mm

B - 37 mm

B₄ - 7 mm

D_b1 - 102 mm

D_b2 - 111 mm

J - 148.5 mm

H - 178.5 mm

L - 111 mm

H - 16 mm

s₁ - 25.8 mm

T - 49.8 mm

J₆ - 120.5 mm

J₇ - 18 mm

N₄ - 2 mm

D_N - 6.579 mm

SW_N - 11.112 mm

G_N - 1/8-27 NPT

R_G - 1/8-27 NPT

R₁ - 24 mm

R_α - 45 °

Basic dynamic load rating - C - 33.2 kN

Basic static load rating - C₀ - 21.6 kN

Fatigue load limit - P_u - 0.915 kN

Limiting speed - 4300 r/min

Mass bearing unit - 1.7 kg

Thread - G₂ - 5/16-24 UNF

Hexagonal key size for grub screw - H - 3.969 mm

Recommended tightening torque for grub screw - 6.5 N·m
