FYNT65F轴承

d_a - 65 mm

A₁ - 78 mm

A₂ - 25 mm

T - max. - 80.3 mm

B - 72 mm

H - 190 mm

H₁ - 95 mm

J - 152 mm

L - 190 mm

D_a - 150 mm

H - 19 mm

a - 6 mm

J₅ - 85 mm

J₆ - 55 mm

N₄ - max. - 8 mm

A₃ - 73 mm

A₅ - 35.5 mm

b_a - min. - 38 mm

b_a - max. - 65 mm

Basic dynamic load rating - C - 193 kN

Basic static load rating - C₀ - 216 kN

Fatigue load limit - P_u - 24 kN

Limiting speed - 2700 r/min

Calculation factor - e - 0.24

Calculation factor - Y₁ - 2.8

Calculation factor - Y₂ - 4.2

Diameter - d_m - 92.5 mm

Basic Designation bearing - 22213 E

P_a - 20 kN

P₁ - 140 kN

P₂ - 125 kN

P₃ - 265 kN

Mass bearing unit - 9.3 kg

Diameter - G - 16 mm
