FYNT55F轴承

d_a - 55 mm

A₁ - 70 mm

A₂ - 15 mm

T - max. - 73.6 mm

B - 66 mm

H - 189 mm

H₁ - 72 mm

J - 180 mm

L - 210 mm

D_a - 120 mm

H - 14 mm

a - 5 mm

J₁ - 84 mm

J₂ - 22 mm

J₃ - 62 mm

J₄ - 54.5 mm

J₅ - 22 mm

J₆ - 84 mm

N₄ - max. - 8 mm

A₃ - 66 mm

A₅ - 34 mm

b_a - min. - 34 mm

b_a - max. - 55 mm

Basic dynamic load rating - C - 125 kN

Basic static load rating - C₀ - 137 kN

Fatigue load limit - P_u - 13.7 kN

Limiting speed - 3100 r/min

Calculation factor - e - 0.24

Calculation factor - Y₁ - 2.8

Calculation factor - Y₂ - 4.2

Diameter - d_m - 77.5 mm

Basic Designation bearing - 22211 E

P_a - 15 kN

P₁ - 120 kN

P₂ - 95 kN

P₃ - 115 kN

Mass bearing unit - 5.9 kg

Diameter - G - 12 mm
