NAO35x55x20轴承
更新日期：2025-11-02简介: SKF轴承NAO35x55x20 类型为滚针轴承，内径：35mm 外径：55mm 厚度：20mm轴承主要应用于仓储货架,粮食检测,液压设备,除颤起搏,水泵行业,成型机类,动态血压,工业用品,压铸模具,磁性材料,钢筋机械等，更多详细资料您可致电我司，获取SKF NAO35x55x20轴承配合尺寸,重量,额定动负荷,载荷,NAO35x55x20极限转速,游隙, 轴承的图纸、样品、价格或者替换产品等！咨询电话:022-58519723/22/21
滚针轴承NAO35x55x20样本图纸
d - 35 mm
D - 55 mm
B - 20 mm
C - 20 mm
r1 min. - 0,3 mm
r2 min. - 0,3 mm
E - 47 mm
F - 40 mm
Da - 47,5 mm
db - 39,5 mm
ra max. - 0,3 mm
S - 0,8 mm
da - 46,2 mm
Db - 40,6 mm
Weight - 0,19 Kg
Basic dynamic load rating (C) - 31,4 kN
Basic static load rating (C0) - 57 kN
Fatigue load limit (Pu) - 6,95
Reference speed - 10 000 r/min
Limiting speed - 11 000 r/min
相同尺寸同类型近似型号
CRAFT NA4907 INA NA4907 INA NAO35X55X20 CONSOLIDATED NA-4907 ISO PNA35/55 CONSOLIDATED PNA-35/55 KOYO NA4907 NSK NA4907 NBS NA4907 ISO NA4907 SKF NAO35x55x20 CONSOLIDATED NAO-35x55x20 CONSOLIDATED NA-4907-2RS NBS PNA35/55 NTN NA4907R CX NA4907 Timken NA4907 CX PNA35/55 NSK NAF355520 CONSOLIDATED NA-4907-RS随机推荐型号
