SN-612..20312-K轴承
更新日期：2025-04-29简介: CONSOLIDATED轴承SN-612..20312-K 类型为轴承座，内径：55mm 外径：mm 厚度：80mm轴承主要应用于园林机械,机械机电,硫化机类,万向节类,海洋测试,编辑设备,电磁铁类,稀金材料,包装材料,事务机类,龙门加工等，更多详细资料您可致电我司，获取CONSOLIDATED SN-612..20312-K轴承配合尺寸,重量,额定动负荷,载荷,SN-612..20312-K极限转速,游隙, 轴承的图纸、样品、价格或者替换产品等！咨询电话:022-58519723/22/21
轴承座SN-612..20312-K样本图纸
| Dimensions (metric) | d | 55 |
|
| b | 80 | ||
| E | 230 | ||
| A | 280 | ||
| L | 125 | ||
| H | 80 | ||
| H1 | 155 | ||
| Housing Only Approx. Wgt.lbs | 16.100 | ||
| Additional Seals / Seal No. | SN-12-TA | ||
| Additional Seals / Seal Qty. | 2 | ||
| Stabilizing Rings Req'd / No. | FR 130/13 | ||
| Stabilizing Rings Req'd / Qty. | 2 | ||
| Suitable Adapter | H-312x55mm. | ||
| Suitable for Bearings | 20312-K | ||
| Interchange | FAG | SN 612 | |
| SKF | SN 612 | ||
| STEYR | SN 612 | ||
| 1) The above are cast-iron split housings and are equipped with felt seals. 2) Felt seals can be substituted with SN-.. TA rubber seals. These seals are not interchangeable with housings from other manufacturers. Consult factory for availability. 3) The above series has two bolt bases and two bolt caps. | |||
