UCP218轴承

(dimensions in mm)

Bearing Type - Extended inner race with set screws

Dynamic Load Rating (Cr) - 95,985

Static Load Rating (Cor) - 71,572

Shaft Dia. (Fw) - 90.0000

Shaft Height (h) - 101.6000

Housing Width (b) - 88.0000

Mounting Hole Center-to-Center (e) - 262.0000

Housing Length (a) - 327.0000

Mounting Slot Length (S2) - 45.0000

Mounting Slot Width (S1) - 27.0000

Housing Base Thickness (g) - 34.0000

Housing Height (w) - 198.0000

Bearing Inner Race Width (Bi) - 96.0000

Bearing Inner Race Width - Short Side (n) - 39.7000

Bearing Inner Race Width - Extended Side (m) - 56.3000

Mounting Bolt Size - 22.0000

Bearing Number - UCP 218

Housing Number - P 218

Shaft Dia., Nominal (d) - 90.0000

Weight (g) - 14,016.00

Material - Cast iron housing, chrome steel bearing

Also available with eccentric locking collar.

Medium Duty, Heavy Duty and other available types are described in the Bearing Types information.

Various seal options and plated housing options are described in the Nomenclature and Bearing Types information.
