LBB32UUOP轴承

(dimensions in inches)

Bearing Type - sealed, open type

Dynamic Load Rating (Cr) - 890

Static Load Rating (Cor) - 2,052

Shaft Dia. (Fw) - 2.000

Outside Dia. (D) - 3.000

Length ( C ) - 4.000

Groove-to-groove length (C1) - 3.192

Groove Width (C2) - 0.103

Groove Dia. (D1) - 2.860

Open Gap (E) - 1.000

Open Gap (a deg.) - 50.00

Weight (g) - 920.00

Material - 52100 chrome steel, or equivalent

The load ratings are based on Load Direction A loading. See the product technical pages for more information.

Tolerance data is available in the product technical pages.

Stainless steel models are available.
